VAG Engine Timing Tool Set (TDI)

 SA-8031

 Specification

This kit has been designed to fit the newest Common Rail diesel engines which are significantly different from the older PD engines. These CR engines combine belt and gear drives by using a toothed belt to transfer the drive from the crankshaft to one of the cam shafts then using gears to transfer the drive from one cam to the other. For 5th Generation Common Rail diesels (Blue Motion). Includes camshaft pulley puller

OEM Code:
T20102 - Injection Pump/Camshaft Alignment Pin
T10050 - Crankshaft Pulley Locking Tool T10100 - Crankshaft Pulley Locking Tool T10264 - Ball End Hex Key 6mm
T40098 - 3.9mm Tensioner Pulley Locking Pin
T10265 - 2.5mm Tensioner Pulley Locking Pin
T10051 - Sprocket Holding Tool T10052 - Cam Sprocket Hub Puller
T10255 - Oil pump | Balancer Shaft Alignment

• Special designed set for alignment camshaft locking and adjusting.
• VM number: 1-T20102, 2-T10050, 3-T10100, 4-T40098, 5-T10265, 6-T10264, 7-T10051, 8/9-T10052, -10T10255
• Applicable: For models 1.6, 2.0 TDi CR engines Audi A3, A4, A5, A6, Q5 Volkswagen Golf, Tiguan, Passat, Eos Seat Exeo

• Engine code: FCA, CAAA, CAAB, CAAC, CAYB, CAYC, CAGA, CAHA, CAGB, CAHB, CAGC, CAVA, CBAB, CBAC, CBBB, CBAA, CBDA, CBDC, CBDD, CCHA, CFFB.

This is high quality Tiawanese specialist tool set.
